제품 JBBS-49-T615/3G
IP67 정션 박스, 6-채널
FOUNDATION 필드버스
주문 번호: 6611446- Junction box for wall mounting with PVC cable glands M20 x 1.5
- Integrated terminating resistor (activatable)
- Cable shielding: Capacitive or direct connection to housing potential selectable via switch
- Isolated support terminal for optional protective conductor incorporated in cable
- Powder-coated die-cast aluminium housing
- Pressure compensation element protects against condensation
- Connection of the housing potential via M5 x 1 bolt
- Entity and FISCO compliant according to IEC 60079-11
General data
| EAN | 4047101207675 |
| eCl@ss-Code (V5.1.4): | 27250201 -/- Network components (fieldbus) |
| Customs tariff number | 85369095000 |
| Country of origin | DE |
| Weight | 734 g |
Technical Data
| 네트워크 프로토콜 | FOUNDATION fieldbus |
| 연결 기술 신호 | 케이블 글랜드 |
| 장치 타입 | 패시브 필드버스 정션 박스 |
| 주위 온도 | -25…+70 °C |
| 보호 등급 | IP67 |
| 인증 | Ex-Approval |
