제품  RKH4-2/TFG

Food & Beverage Hygienic, TPE

Connection Cable

주문 번호: 6934384
    • M12 female connector, straight, 3-pin
    • Stainless steel coupling nut/screw
    • Sheath material: TPE-O
    • Sheath color: light gray RAL 7035
    • Qualified for drag chain use
    • Resistant to chemicals an microbes
    • Weatherproof
    • Resistant to hydrolysis acc. to DIN EN 60068-2-78
    • Flexible at low temperatures
    • Free from silicone and PVC
    • Halogen-free acc. to DIN EN 50267-2-1, IEC 60754-1, VDE 0482-267-2-1
    • Approvals: Gost, Ecolab, FDA
    • RoHS and REACH compliant
    • Protection classes IP67, IP69K
    • Cable length: 2.0 m
#

General data

EAN 4047101363890
eCl@ss-Code (V5.1.4): 27250107 -/- Connection cable sensor-actuator
Customs tariff number 85444290900
Country of origin DE
Weight 68 g

Technical Data

어플리케이션 식품(식음료), 신호
디자인 연결 케이블
커넥터 A female, M12 x 1, 일자형
핀의 수 3
Connector body 플라스틱, PP, 회색
Coupling nut/screw 스테인리스 스틸, V4A
정격 전압 250 V
전류 4 A
케이블 직경 Ø  4.6 mm
Cable length 2.0 m
Cable jacket TPE-O, 회색
Number of Conductors 4
보호 등급 IP65, IP67, IP68, IP69

설치 액세서리

6936170
